Items | Value |
---|---|
Pixel Pitch | 6mm |
Physical Density | 27,778 pixels/m² |
Scan method | 1/8 |
LED Arrangement | SMD3528 white LED (black LED optional) |
Module Resolution | 32x16 pixels |
Module Dimension | 192x96 mm |
Cabinet Resolution | 96x96 pixels |
Cabinet Dimension | 576x576 mm |
Cabinet Weight | 10kg |
Brightness Level | ≥1,800cd/m² |
Max Power Consumption | 300W/panel |
Ave Power Consumption | 100W/panel |
Viewing Angle | 140°/140° |
Operating Power Source | AC90-260V 50-60Hz |
Operating Temperature | −10°- 45°C |
Refresh Rate | ≥1,800Hz |
Transparent Rate | N/A |
Life Span | 100,000Hours |
MTBF | 5,000Hours |
Protecting Rating | IP31 |
Signal Input Source | Composite, S-Video, Component, VGA, DVI, HDMI, SDI, HD SDI |
Curvable | N/A |
Max Rigging | 11.52m or 20 panels |
Verification | CE |
